Custom Elite Trailer

Elite

For many years, EZ Loader Customs has relied upon the sales of our M2 series as it has been our most popular and biggest volume of trailers sold. It has been the standard for years. It really has not changed much…until NOW.

In conjunction with the new Watersport Line of Trailers from EZ Loader, our M2 line has been redesigned into what is now called the Watersport Elite Series…for the Elite consumer. The Elite Series features many options and configurations for i/O’s, O/B’s, Forward Drives, and Inboards, each with their own separate and individual model numbers. The Elite Series comes standard with New Aluminum Turismo Wheels on most models, molded steps front and rear cover with “Surf Turf”, (in gray or teak color), for more comfort loading and unloading. Optional Laser cut steps are available along with traditional Brite Steps with lighted logos, lighted tops, and radial tires. Not just the ordinary….it is the Elite and as with all trailers, they have a five year from retail sale or 6 years from Manufacturing date warranty and are NMMA Certified and NATM Compliant.

FEATURES

SPECS

Elite 10/OB
Model Capacity GVWR Approx. Length Construction Finish # of Axles Suspension Brakes Wheels Tires
WSE1800 1800 2360 15-18 Tube Painted Single Spring N/A 13 Alum CROSSTRAC ST175/80R13C
WSE2160 2160 2720 16-18 Tube Painted Single Spring N/A 13 Alum CROSSTRAC ST175/80R13C
WSE2350 2350 2995 16-18 Tube Painted Single Spring N/A 14 Alum TURISMO ST205/75/R14C
WSE2500 2500 3240 16-18 Tube Painted Single Spring Disc/1 Axle 14 Alum TURISMO ST205/75R14C
WSE3000 3000 3740 16-18 Tube Painted Single Spring Disc/1 Axle 14 Alum TURISMO ST215/75R14C
WSE3850 3850 4750 18-20 Tube Painted Single Spring Disc/1 Axle 15 Alum 6H TURISMO SST225/75R15D
WSE4200 4000 5100 20-22 Tube Painted Tandem Spring Disc/2 Axles 14 Alum TURISMO ST205/75R14C
WSE4600 4400 4800 22-24 Tube Painted Tandem Spring Disc/2 Axles 14 Alum TURISMO ST205/75R14C
WSE5200 5200 6500 22-24 Tube Painted Tandem Spring Disc/2 Axles 14 Alum TURISMO ST205/75R14C
WSE5800 5800 7200 24-26 Tube Painted Tandem Spring Disc/2 Axles 14 Alum TURISMO ST215/75R14C
WSE6300 6300 8250 24-27 Tube Painted Tandem Spring Disc/2 Axles 15 Alum 5H TURISMO ST205/75R15D
WSE7900 7900 9900 25-27 Tube Painted Tandem Spring Disc/2 Axles 15 Alum 6H TURISMO ST225/75R15D
WSE10000 10000 13002 27-30 Tube Painted Tri-Axle Spring E Drum/3 Axles 15 Alum 6H TURISMO ST225/75R15D
WSE14500 14500 18000 30-32 Tube Painted Tri-Axle Spring E Drum/3 Axles 16 Alum 8H ST235/85r16e
Elite Forward Drive
Model Capacity GVWR Approx. Length Construction Finish # of Axles Suspension Brakes Wheels Tires
WSEf3300 3300 4200 18-20 Tube Painted Single Spring Disc/1 Axle 15 Alum 5H TURISMO ST205/75R15D
WSEf3850 3850 4750 18-20 Tube Painted Single Spring Disc/1 Axle 15 Alum 6H TURISMO ST225/75R15D
WSEf4200 4200 5300 18-20 Tube Painted Tandem Spring Disc/2 Axles 14 Alum TURISMO ST205/75R14C
WSEf4600 4600 5800 20-22 Tube Painted Tandem Spring Disc/2 Axles 14 Alum TURISMO ST205/75R14C
WSEf5200 5200 6500 22-24 Tube Painted Tandem Spring Disc/2 Axles 14 Alum TURISMO ST205/75/R14C
WSEf5800 5800 7400 22-24 Tube Painted Tandem Spring Disc/2 Axles 14 Alum Turismo ST215/75R14C
WSEf6300 6300 8250 24-26 Tube Painted Tandem Spring Disc/2 Axles 15 Alum 5H TURISMO ST205/75/R15D
WSEf7900 7900 9900 24-26 Tube Painted Tandem Spring Disc/2 Axles 15 Alum 6H TURISMO ST225/75R15D
WSEf8000 8000 9990 26-28 Tube Painted Tri-Axle Spring Disc/3 Axles 15 Alum 5H TURISMO ST205/75/R15D
Elite Inboard
Model Capacity GVWR Approx. Length Construction Finish # of Axles Suspension Brakes Wheels Tires
WSEi3300 3300 4200 18-20 Tube Painted Single Torsion Disc/1 Axle 15 Alum 5H TURISMO ST205/75R15D
WSEi3850 3850 4750 18-20 Tube Painted Single Torsion Disc/1 Axle 15 Alum 6H TURISMO ST225/75R15D
WSEi4200 4200 4300 18-20 Tube Painted Tandem Torsion Disc/2 Axles 14 Alum TURISMO ST205/75R14D
WSEi4600 4600 5800 20-22 Tube Painted Tandem Torsion Disc/2 Axles 14 Alum TURISMO ST205/75R14C
WSEi5200 5200 6500 22-24 Tube Painted Tandem Torsion Disc/2 Axles 14 Alum TURISMO ST205/75/R14C
WSEi5800 5800 7400 22-24 Tube Painted Tandem Torsion Disc/2 Axles 14 Alum TURISMO ST215/75R14C
WSEi6300 6300 8250 22-23 Tube Painted Tandem Torsion Disc/2 Axles 15 Alum 5H TURISMO ST205/75/R15D
WSEi7900 7900 9900 24-25 Tube Painted Tandem Torsion Disc/2 Axles 15 Alum 6H TURISMO ST225/75R15D
WSEi8000 8000 9990 24-25 Tube Painted Tri-Axle Spring Disc/3 Axles 15 Alum 5H TURISMO ST205/75/R15D
